CSRC20J5L00B00

Published Time: 2024-07-23 17:04:35
CSRC20J5L00B00 Datasheet Stocking Manufacturer ROYALOHM Resistor RES.SHUNT 5m Ohms 5% NONE RADIAL TYPE-C THT

ROYALOHM  Datasheet: CSRC20J5L00B00.pdf




Description:

Manufacturer ROYALOHM Resistor RES.SHUNT 5m Ohms 5% NONE RADIAL TYPE-C THT


Features:

  • Made by Cu/Ni or Mn/Cu Alloy resistance wire materials

  • Excellent solderability

  • Suitable for all kinds of current sense application

  • Application: Power Supply


Specification:


φDRated CurrentResistance RangeTCR
CSRA
CSRB
CSRC
CSRD
φ0.8mm4.5A5mΩ~50mΩ±100PPM/℃
φ0.9mm5.0A5mΩ~40mΩ
Φ1.0mm5.5A3mΩ~30mΩ
Φ1.1mm6.0A3mΩ~20mΩ
Φ1.2mm7.0A3mΩ~20mΩ
01.3mm7.5A3mΩ~20mΩ
Φ1.4mm8.0A3mΩ~20mΩ
Φ1.5mm9.0A3mΩ~20mΩ
Φ1.6mm9.5A3mΩ~15mΩ
Φ1.8mm11A3mΩ~10mΩ
φ2.0mm12A3mΩ~10mΩ
Φ2.3mm14A3mΩ~7mΩ
CSREΦ1.0mm50A1mΩ
