NCP4545IMNTWG-L onsemi

Name: NCP4545IMNTWG-L
Brand: Perceptive Component Limited
SKU: NCP4545IMNTWG-L
Price: 0.001 USD
Availability: InStock
Rating: 88 (96 reviews)

Technical Parameters

Part Status	Active
Switch Type	General Purpose
Number of Outputs	1
Ratio-Input	Output
Output Configuration	High Side
Output Type	N-Channel
Interface	On/Off
Voltage-Load	3V ~ 5.5V
Voltage-Supply(Vcc/Vdd)	Not Required
Current-Output(Max)	10.5A
Rds On(Typ)	4.9mOhm
Input Type	Non-Inverting
Features	Slew Rate Controlled
Fault Protection	-
Operating Temperature	0°C ~ 70°C (TA)
Mounting Type	Surface Mount
Supplier Device Package	18-QFN (3x3)
Package/Case	18-VFQFN Exposed Pad
Base Product Number	NCP4545
RoHS Status	ROHS3 Compliant
Moisture Sensitivity Level(MSL)	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
